Wilmette Fire Department open house

The Wilmette FD had an open house Saturday morning (5/18/19). This included several antique apparatus and an opportunity to showcase new Engine 27 for residents followed by ceremoniously pushing it into the station.

Engine 27 is a 2019 Pierce Dash CF PUC so 32569. It has a 1500-GPM pump, 750 gallons of water, and a foam cell which has either a 20 or 30-gallon capacity. This engine was outfitted with a 35-foot ground ladder and will run as Engine 26 if the tower ladder is out of service. It will go into service at Station 27, and the 2017 2013 E-ONE engine will become a reserve piece.

Wilmette FD Fire Chief Ben Wozney

Larry Shapiro photo

Wilmette FD Engine 27 2019 Pierce Dash CF PUC

; Wilmette FD Engine 27; Pierce Dash CF PUC

active and retired firefighters push new fire engine into the station

Larry Shapiro photo

active and retired firefighters pose with new fire engine

Larry Shapiro photo

Wilmette sold the reserve tower ladder and has an engine currently for sale.



Tags: , , , , , , , , , ,

Chicago FD apparatus history

More photos from Steve Redick of past CFD apparatus

Chicago FD Engine 43

Steve Redick photo

Ford C - Pierce fire engine

Steve Redick photo

old Chicago fire house with pumper and ambulance

Steve Redick photo

E-ONE Hurricane fire engine

Steve Redick photo

vintage Chicago fire trucks at fire station

Steve Redick photo

vintage Seagrave ladder truck in Chicago

Steve Redick photo

Hendrickson - E-ONE ladder truck in Chicago

Steve Redick photo

Chicago FD Engine 43

Steve Redick photo

vintage Seagrave ladder truck in Chicago

Steve Redick photo

E-ONE Hurricane fire engine

Steve Redick photo

E-ONE Hurricane fire engine

Steve Redick photo

Tags: , , , , , , , , , , , ,

A historical look … from NYC The Super Pumper System

A reader thought this article would be of interest to others … so forgive the out of area nature of the article:

In the early 1960s the New York City Fire Department was facing a host of problems. The world around them was growing ever taller, ever more compact, and ever more dangerous with respect to fire. There were times when the very infrastructure that was supposed to be supplying them the water to extinguish a blaze simply stopped flowing, there were other times that the equipment they had proved to be woefully insufficient to stop a fire that should have been controlled, resulting in massive blazes that ate up homes, businesses, lives, and millions upon millions of dollars. In April of 1963, a massive fire on Staten Island taxed the city’s fire service to the absolute breaking point while destroying millions and millions in property.

The day is still referred to as Black Saturday by the people who lived through it. Due to the lack of suitable water supplies, the fire was far larger than it should have been. There was a drought that year and many of the sources that the firemen were used to pulling water from had literally run dry. This began a series of events that led to the construction of the most powerful land based fire fighting truck ever created, the Mack Super Pumper System. It was actually five trucks that worked as a brigade to battle the worst flaming disasters that the city could throw at it.

From 1965 through the early 1980s, the Mack Super Pumper System responded to more than 2,200 calls with more than 900 firefighters serving to operate it in some capacity. The five trucks that made up the super pumper system were a massive, locomotive-engined central pumping truck, a tender truck full of hoses, manifolds, and other gear, and three satellite trucks that looked like standard fire engines but were not equipped with their own pumps. It cost the city of New York $875,000 when it was new and we’ll wager to say that it was probably the best money ever spent to keep Gotham safe. There’s never been anything else like it.

The pumping unit –

The keystone of the whole operation was the massive central pumping unit that could draw water from eight hydrants at once, drop lines into bodies of water, supply a mind-boggling number of lines with water simultaneously, and flow over 10,000 gallons per minute at low pressures if the situation called for it. When the pressure was ramped up to to 350psi, it could move 8,800 GPM. This was enough to supply the other satellite trucks as well as feed a massive water cannon on the tender truck that could heave water over 600ft. That’s right, nearly and eight of a mile in whatever direction you wanted it to go. How was this possible? It was possible because of innovations in diesel engine technology during WWII. The grunt for the Super Pumper system came from a Napier-Deltic diesel engine. This was an engine designed by the British during WWII as a lightweight, high speed means to propel their ships. Making 2,400 horsepower and even more prodigious torque numbers, the engine was “light” enough to be mounted in a trailer behind a tractor and carted around. The Napier-Deltic was used to power locomotives and other massive land craft as well for a while. The engine’s design is interesting in the fact that it had three crankshafts and was an opposed piston style engine meaning that the pistons travel at each other. With turbochargers and a two stroke design, it was as mighty a compact piston powered engine the world had ever known to that point. It was thirsty and noisy as well. When working at full song, the engine would consume 137 gallons of diesel fuel per hour and the noise was so deafening that firemen near the truck had to wear strong ear protection to prevent hearing damage.

Mack was awarded the contract to build the truck in 1964 and by the end of the year, the unit was nearly ready to hit the streets of NYC. The tractor employed to drag the pumping unit around was a F715FSTP cab over that used a 255hp Mack END864 engine. The top speed of the whole rig was 42mph but since it was intended for responding to calls in the city, high mph was not as much a concern as maneuverability, and the ability to zip around at lower speeds happily. There were custom built PTOs to power the priming pump for the water pump and to to run an air compressor that needed 450psi to light off the pump engine.

The custom built trailer housed the engine and all of the stuff needed to keep it alive like the cooling system, fuel tanks, etc. At the rear of the trailer was the enormous six stage pump which was built by a company called DeLaval and that’s where the real magic happened. When the big Deltic was put to work turning that bad boy, fire, at least any on the first 60 stories of a building, didn’t stand a chance. The whole rig weighed in at 68,000lbs and for as much reading and research as we have done, there are no accounts of it ever faltering, failing, or leaving firefighters without the resources they needed to battle a fire. Often times we read about awesome machines like this and discover that they were unreliable or prone to fail but not this big guy.

Some pretty stunning facts about the truck and the pumper:

At 8,800 GPM it was throwing nearly 70,000lbs of water on a fire per minute.

During a fire in the Bronx, firemen laid 7,000ft of hose to get to a suitable water supply and the truck pumped as though it was dipping its feet into the ocean.

In 1967 the Super Pumper responded to a fire at a postal annex in NYC and managed to supply water to the massive gun on the tender truck, its three satellite units, two tower ladder trucks, and a portable manifold with multiple hand lines all by itself.

The hoses on the truck were pressure tested to 1,000psi of pressure but typically operated anywhere in the 350-800psi  range depending on the situation. This is way higher (by several times!) what modern trucks use by our understanding. The hoses were a derivative of hoses developed by the Navy in WWII for high pressure applications and while incredibly heavy when compared to modern hoses, they were cutting edge at the time.

The truck still exists, living at a museum in Michigan and standing as a great reminder that human beings are amazingly inventive and creative beings when forced to find solutions to problems that endanger lots of lives or lots of valuable property!

thanks Dan

The article at bangshift.com includes several photos.

Tags: , ,

Of interest … vintage Maxim fire truck brochure

This from Mike Summa:

I found this brochure I sent for a long time ago.  I would like to share them with you.  Enjoy and comment.

Mike Summa
1972 Maxim Fire Trucks brochure cover

click open the photo for a larger version

Tags: , ,

Vintage Chicago FD

This from Eric Haak:

For #TBT. I wanted to share these great color images taken in the Summer of 1963 of Truck 49 and Engine 126 outside of their quarters. No idea who the lucky young man is.

Vintage photo of Chicago FD H&L 49 circa 1950

photographer unknown

Vintage photo of Chicago FD Engine 126 circa 1950

photographer unknown

Tags: , , , , , , , , ,

Historic 3-11 Alarm fire in Chicago, 2-22-89

This from Steve Redick:

2-22-89, a 3-11 alarm at the Rose of Sharon Church. LODD of FF  Kelvin Anderson from Engine 107. It was a busy night, cold temperatures and snow.
I was working on some of my old audio and thought I would share this.
Steve

Tags: , , , , ,

Chicago FD history at O’Hare Airport

For #TBT from Steve Redick, some vintage photos of apparatus at O’Hare Airport

Chicago FD O'Hare Airport ARFF 655

Steve Redick photo

Chicago FD O'Hare Airport ARFF 6511

Steve Redick photo

Chicago FD O'Hare Airport ARFF 6511

Steve Redick photo

Chicago FD Squad 7A

Steve Redick photo

Chicago FD Squad 12 at O'Hare Airport

Steve Redick photo

Chicago FD Truck 3 at O'Hare Airport

Steve Redick photo

Tags: , , , , , , , , , , , , ,

Orland FPD history

This from Mike Summa for #TBT:

For TBT – With the 50th Anniversary of the Orland Fire Protection District this year, here is a glimpse of their pre-district days.  It is a tanker built on a 1940’s International chassis.  If anyone knows more information, please feel free to inform.

Mike Summa
1940's era fire engine from the Orland Park Volunteer Fire Department

Tags: , , , , , , , ,

Palos FPD history

This from Mike Summa for #TBT:

For TBT-The Palos FPD’s Squad 6305, 1977 GMC/E-One 250/500.
Mike Summa
Palos FPD Squad 6305 - 1977 GMC/E-One 250/500

Mike Summa photo

Tags: , , , , , ,

Chicago Fire Department history

photo of unknown details from the CFD APPARATUS GROUP ON FACEBOOK

vintage Cadillac ambulance

Jeff Norton

thanks Steve
